Varioport Pirol 2.0 -90, VAC, NIST

Varioport Pirol -90 (2.0)

Medical, portable suction unit for vacuum
for holding 2 secretion canisters.

The canister holder is universal. Common canisters in
sizes 0.5 to 3.0 L from various manufacturers can be used
(e.g. Serres, Abbott, Medela, Ardo, Cardinal, etc.).
The carrying frame features a sturdy handle and a mount for
a 25x10mm equipment rail. The vacuum control unit is located
at the front, allowing the operator quick and direct access.
The gas inlet as a NIST coupling is located at the rear of
the device, so that the supply hose is outside the working area.

Scope of delivery:
- Vacuum regulator Pirol-90 with fine control valve, rotating vacuum gauge
- Carrying frame, coated
- 2 highly flexible retaining cuffs

Technical data:
Gas type: Vacuum - VAC
Connection: NIST according to DIN EN ISO 18082
Outlet: 9/16-18 UNF with vacuum nozzle
Performance: adjustable between 0 and -85 kPa
Weight: approx. 3 kg (without canisters)
