Medical Technology Accessories
Half-size support plate
Carrying plate for emergency supply unit; complete with cylinder holder and carrying handle Suitable for hanging on a medical rail or bed. Dimensions: approx. W 165 x H 520 x D 120 mm
Hose Connection 9/16 Nipple -Compressed Gas
Hose connection for flowmeters Connector screw with union nut 9/16-18UNF for med. hoses Inlet: 9/16-18UNF Outlet: 6 mm flow nozzle
Replacement Plate Portable Emergency Supply
Replacement plate for HABICHT Portable emergency supply unit Carrying plate for emergency supply unit complete with cylinder holder and carrying handle Material: V2A stainless steel Dimensions: 520x330x120 mm (HxWxD) Suitable for attachment to an equipment rail or bed. Mounting suitable for gas cylinders with 100 mm diameter
Y-connector, DIN AIR
Y-Distributor for Compressed Air compl. with 2 DIN self-sealing couplings Gas Type: Compressed Air/Air Inlet: Probe according to DIN 13260 Part 2 Outlet: 2 x self-sealing coupling according to DIN 13260 Part 2
Y-connector, DIN O2
Y-piece for oxygen compl. with 2 quick-connect couplings Gas type: Oxygen/O2 Inlet: Probe according to DIN 13260 Part 2 Outlet: 2 x quick-connect coupling according to DIN 13260 Part 2
Y-Distributor, DIN CO2
Y-Distributor for Carbon Dioxide compl. with 2 quick-release couplings Gas type: Carbon dioxide/Co2 Inlet: Probe according to DIN 13260 Part 2 Outlet: 2 x Socket according to DIN 13260 Part 2
Y-piece, DIN AIR - ANTIMAGNETIC
Y-Distributor for Compressed Air complete with 2 DIN couplings **** ANTIMAGNETIC **** Inlet: Probe according to DIN 13260 Part 2 Outlet: 2x Coupling according to DIN 13260 Part 2
Y-piece, DIN O2 - ANTIMAGNETIC
Y-Distributor for Oxygen complete with 2 DIN couplings **** NON-MAGNETIC **** Inlet: Probe according to DIN 13260 Part 2 Outlet: 2x Couplings according to DIN 13260 Part 2
Supplementary components for your medical technology systems.
Our medical accessories include practical solutions to complement our devices. They complete the portfolio and simplify installation, operation and organisation in everyday clinical practice.
