Kolibri 2 Rail NIST O2 Paediatric

KOLIBRI 2, O2, 0...5 l/min
- Paediatric RAIL UNIT -
Increments:
0 / 0.1 / 0.3 / 0.5 / 0.6 / 0.8 / 1 / 2 / 3 / 4 / 5 l/min

KOLIBRI 2 multi-step compact flowmeter
with fixed orifices and selection device

Medical compact flowmeter for mounting on a
25x10mm medical rail; NIST gas inlet integrated into the
rail clamp; with handwheel - incrementally
adjustable flow, outlet 9/16-18 UNF thread

Adjustment device ergonomically optimised and readability
of the set flow step possible from various view directions
and angles.

Frontal operating concept -> increased safety when
setting the correct flow rate

Gas type:     Oxygen / O2
Connection: NIST according to DIN EN ISO 18082
Outlet:     9/16-18 UNF
Performance:     0...5 l/min at 450 kPa (4.5 bar) inlet pressure

Required accessories for operation:
900619 - Hose connection 9/16-18 UNF
